A.Technical parameter: It can be set the action of the welding head,welding current,welding time,emergency stop etc. Through the change-over switch to realize the adjustment between the actions,and keep the whole welding procedure working continuously.
Max compaction force of oil cylinder 30KN
Max upsetting force of oil cylinder 60KN
Vertical stroke of left electrode 80mm (can satisfy product processing requirement
that the customer provides)
Feeding stroke of right electrode 150 mm (can satisfy product processing requirement
that the customers provide)
Cooling way: transformer,silicon controlled,hydraulic oil return are water cooling
| Input voltage | Single phase AC380V±10% |
| Welding transformer | AC 200KVA |
| Control system | Touch screen+PLC+microcomputer |
| Max width of workpiece | 120mm |
| Max Welding ability | 350mm2(die-casting aluminum) |
| Working speed | about 20s/pcs |
| Products withstand voltage test | 18kgs(air pressure)can keep no leak one minute |
| Operation availability | 100%(calculated according to operation rate by the month) |
B. Accessories: | 200KVA AC transformer | According to CCC standard |
| 7 inch touch screen | Delta |
| PLC | Delta |
| 24V intermediate relay | OMRON |
| 500A Silicon controlled | China,Jiangsu |
| AC Contactor | Hangzhou Hupai |
| Three phase 11KW motor | Shanghai electric |
| Vane pump | RISUNY |
| Hydraulic value | RISUNY |
| Pilot operated check valve | RISUNY |
| Throttle | RISUNY |
| Button switch | SCHNEIDER |
| Inductive switch | SCHNEIDER |
We, Ningbo Xin Chang Machinery Co.,Ltd are a professional designer and manufacturer in Friction Welding Machine, Resistance Welding Machine and Heat exchanger equipment. Our factory is in this line more than 20 years, we have more than 10 senior mechanical and electrical specialists and total more than 200 staff, our machine is famous in China. We have CCC, ISO9001 and CE certificates.
Over the years, we have exported so many machines to 30 and more countries, such as France,Spain,Poland,Russia,Indonesia,Vietnam,Pakistan,India,Mexico,Egypt etc.
Our main products are Heat exchanger equipment, Friction welding machine, Spot Welding Machine, Projection Welding Machine, Butt Welding Machine, Seam Welding Machine, Multi Head Welding Machine For Wire Mesh, and other various special welding machine for metal connection in different industries.
We always adhere to the management idea of "Integrity, profession, innovation, and win-win", to make Xin Chang becomes trustworthy enterprise of customers. Good product quality, perfect after-sales service, and professional technical support make customers choose no regrets and worry-free use.
