Condenser Coil Bending Machine

Coil Bending Machine: a precision master for forming Condenser coils

In the core process of condenser manufacturing, each step of the forming process directly affects the heat dissipation efficiency and operational stability of the equipment. The Friction Welding Machine provides high-strength welding for the heavy-duty connecting pipe fittings of the condenser, ensuring structural stability in a high-pressure refrigerant environment.



The Spot Welding Machine can quickly complete the spot welding and fixation of the coil and the heat dissipation fins, reducing thermal deformation while ensuring the connection strength. The Butt Welding Machine precisely connects the long pipeline of the condenser to ensure the seamless flow of the refrigerant circulation system. The Seam Welding Machine creates continuous sealed welds for the condenser shell to strictly prevent refrigerant leakage and the intrusion of external impurities. The Laser Welding Machine for Steel Ring achieves micron-level precision welding for the steel components of the condenser motor, ensuring the long-term reliable operation of the drive system. The Stud Welding Machine efficiently completes the stud fixation of the coil bracket, providing a solid support for the assembly of the internal structure of the condenser. And the Condenser Coil Bending Machine, as a key equipment specializing in the bending forming of Condenser coils, with its excellent precision control, becomes the core guarantee for the efficient heat dissipation of condensers. ​

The bending shape of the condenser coil directly determines the utilization rate of the heat exchange area and the rationality of the refrigerant flow path. The Condenser Coil Bending Machine is equipped with a multi-axis linkage numerical control system, which can control the bending Angle error of the coil within ±0.1° and maintain the curvature radius accuracy at the 0.05mm level, perfectly meeting the design requirements of condensers of different powers. Its unique mold design can automatically adjust the clamping force according to the material of the coil (such as red copper, aluminum-manganese alloy), avoiding wrinkles or fractures of thin-walled tubes during the bending process, ensuring a smooth inner wall of the coil and reducing the resistance of refrigerant flow. ​

From the perspective of coordination with various welding equipment, the coils formed by the Condenser Coil Bending Machine form an efficient coordination with them in the production process. For example, in the production of automotive air conditioning condensers, the serpentine coil bent by this equipment forms a tight connection with the liquid distribution head welded by the Friction Welding Machine. The precise coil size ensures the concentricity during welding and improves the uniformity of refrigerant distribution by 20%.



In the assembly of the condenser of the industrial chiller, the processed spiral coil is combined with the shell welded by the Seam Welding Machine. The regular arrangement of the coil maximizes the utilization rate of the heat exchange area and increases the heat dissipation efficiency by 15%. ​

In addition, the coil formed by this equipment creates a high-quality foundation for the subsequent welding process. Its smooth curved transition section enables the Spot Welding Machine to achieve uniform weld point distribution when welding fins, avoiding false welding caused by coil deformation. The precise coil spacing enables the Butt Welding Machine to achieve a perfect fit when joining pipes without additional straightening, reducing welding defects. Meanwhile, its stable forming quality echoes the precise Welding of the Laser Welding Machine for Steel Ring, jointly enhancing the overall reliability of the condenser and prolonging the service life of the equipment. ​

Not only that, the continuous production capacity of the Condenser Coil Bending Machine is highly matched with the efficient rhythm of equipment such as the Stud Welding Machine. It can achieve continuous bending and forming of the coil through an automatic feeding mechanism, and in combination with the assembly line operation of welding equipment, shorten the production cycle of the condenser by nearly 30%, significantly enhancing the enterprise's production capacity and market response speed. ​

In conclusion, the Condenser Coil Bending Machine, with its extremely precise control of coil bending, builds an efficient production chain for Condenser manufacturing together with various equipment such as the Friction Welding Machine and Seam Welding Machine. It is not only the "shaping master" of coil forming, but also a key link in enhancing the performance of condensers, providing high-quality core component guarantees for fields such as refrigeration and HVAC. ​
