Friction welding belongs to the category of pressure welding technology, which relies on the rotational friction heat generated between workpieces to heat the welding ends until they reach a thermoplastic state. With rapid axial upsetting and solidification, the precise and firm connection of workpieces can be completed efficiently. This welding process features stable forming, small welding deformation and high joint strength, widely applicable to the butt welding of various metal materials such as copper, aluminum, steel and alloy parts.
Our professionally developed Friction Welding Machine adopts mature friction welding principle and optimized mechanical structure, perfectly adapting to workpiece welding demands of different specifications and shapes. As a mainstream type in the product line, the
Rotary Friction Welding Machine relies on stable rotary transmission performance to ensure uniform friction heat generation and consistent welding quality in every operation. Equipped with intelligent control system, the supporting
Automatic Welding Machine realizes one-click start, automatic positioning, constant pressure upsetting and automatic shutdown, effectively reducing manual intervention and improving overall production efficiency.
We configure tailored equipment models and technical parameters according to customer workpiece types, sizes and production output requirements, providing reliable and cost-effective friction welding solutions for industrial manufacturing fields.
| Technical Parameters of Y Series Friction Welding Machine |
| Y120-C | Y120-D |
| Product Name | Continuous-drive Friction Welding Machine | Unit | Product Name | Continuous-drive Friction Welding Machine | Unit |
| Model | Y120-C | | Model | Y 120-D | |
| Max. Upset Force | 800 | Kg | Max. Upset Force | 800 | Kg |
| Spindle Rotating Speed | 2800 | r/min | Spindle Rotating Speed | 2800 | r/min |
| Weldment Diameter | 5--12 | mm | Weldment Diameter | 5--12 | mm |
| Rotary Clamp Material Length | 5-120 | mm | Rotary Clamp Material Length | 5-120 | mm |
| Mobile Clamp Material Length | 3-400 | mm | Mobile Clamp Material Length | 5-120 | mm |
| Max Stroke of Sliding Table | 125 | mm | Max Stroke of Sliding Table | 125 | mm |
| Spindle Motor Power | 4-7.5 | KW | Spindle Motor Power | 4-7.5 | KW |
| Max. Pressure | 8 | Kg | Max. Pressure | 8 | Kg |
| Productivity | 200-400 | Pcs/h | Productivity | 200-400 | Pcs/h |
| Weight | 0.8 | Ton | Weight | 0.8 | Ton |
| Main Unit Dimension | 1300X550X1200 | mm | Main Unit Dimension | 1300X550X1200 | mm |
| Y150-C | Y150-D |
| Product Name | Continuous-drive friction welding machine | Unit | Product Name | Continuous-drive friction welding machine | Unit |
| Model | Y150-C | | Model | Y150-D | |
| Max. Upset Force | 8 | Ton | Max. Upset Force | 8 | Ton |
| Spindle Rotating Speed | 2500 | r/min | Spindle Rotating Speed | 2500 | r/min |
| Weldment Diameter | 8--20 | mm | Weldment Diameter | 8--20 | mm |
| Rotary Clamp Material Length | 3-200 | mm | Rotary Clamp Material Length | 3-200 | mm |
| Mobile Clamp Material Length | 5-500 | mm | Mobile Clamp Material Length | 3-200 | mm |
| Max Stroke Of Sliding Table | 200 | mm | Max Stroke of Sliding Table | 200 | mm |
| Spindle Motor Power | 7.5-11 | KW | Spindle Motor Power | 7.5-11 | KW |
| Max. Pressure | 8 | Kg | Max. Pressure | 8 | Kg |
| Productivity | 300 | Pcs/h | Productivity | 300 | Pcs/h |
| Weight | 1.5 | Ton | Weight | 1.5 | Ton |
| Main Unit Dimension | 2000X650X1200 | mm | Main Unit Dimension | 2000X650X1200 | mm |
