A. Model and specifications
| Model | XC-K53-1000 | XC-K92-1000 | XC-K160-1000 |
| Laser power | 1000W | 1000W | 1000W |
| Steel strip width | 8-53mm | 45-92mm | 80-160mm |
| Welding capacity | 14-18 pcs/min | 12 pcs/min | 10pcs/min |
| Steel strip thickness | 0.13-0.7mm | 0.2-0.5mm | 0.2-0.4mm |
| Steel ring diameter | 65-700mm | 85-700mm | 120-700mm |
| Total machine power | 5kw | 5kw | 5kw |
| Input voltage | 220V | 220V | 220V |
| Nitrogen protection | Optional | Optional | Optional |
| Mark function | Optional | Optional | Optional |
| Cooling mode | Water | Water | Water |
| Machine weight | 1350kg | 1350kg | 1350kg |
| Overall size | 148x128x168 cm | 148x128x168 cm | 148x128x168 cm |
B. Application
Suitable for stainless steel strips applied to glass covers, baskets, flour sieves, enamel pots, trash cans, steamers and other daily necessities. Supporting strip width 10-200mm and thickness 0.1-1mm, it is compatible with SS430/410/304/202/201, GI, Tinplate and other raw materials, making this Laser Equipment highly versatile for sheet metal processing.
C. Advantages
Elegant overall design with a small footprint, perfectly fitting limited workshop layouts.
Adopting built-in fiber continuous laser, it requires no extra external installation area.
Welding capacity reaches 10-20 pcs at a time, bringing remarkable production efficiency.
It is highly applicable to seamless steel ring welding with outstanding finished weld quality.
Streamlined circuit layout enables stable running and lower power consumption for the Automatic Welding Machine.
Complicated operating procedures are omitted; the HMI interface delivers easy operation, where users only need to set the laser proportion parameter.
D. Main configuration
Automatic forming servo tooling: self-made
Control system: Raynen
Fiber continuous laser: BWT/MAX
Cooling water chiller: Hanli
E. Welding samples photos:
