A. Model and specifications
| Item | Machine Models |
| Machine model | ZJ-GL1000-50A | ZJ-GL1000-95A | ZJ-GL1000-125A | ZJ-GL1000-/185A | ZJ-GL1000-200A |
| Max welding width | 10-45mm | 30-90mm | 50-120mm | 70-180mm | 70-200mm |
| Ring diameter | φ90-2000mm | φ90-2000mm | φ90-2000mm | φ90-2000mm | φ90-2000mm |
| Workpiece material | SS430/410/304/202/201,GI,Tinplate etc |
| Welding thickness | 0.1-1.0mm | 0.10-0.5mm | 0.10-0.5mm | 0.10-0.5mm | 0.10-0.5mm |
| Machine total power | 8KW | 8KW | 8KW | 8KW | 8KW |
| Laser power | 1KW | 1KW | 1KW | 1KW | 1KW |
| Input voltage | AC380V/3P | AC380V/3P | AC380V/3P | AC380V/3P | AC380V/3P |
| HZ | 50/60Hz | 50/60Hz | 50/60Hz | 50/60Hz | 50/60Hz |
| Duty cycle | 100% | 100% | 100% | 100% | 100% |
| Working temperature | 0-45° | 0-45° | 0-45° | 0-45° | 0-45° |
| Humidity | ≤85% | ≤85% | ≤85% | ≤85% | ≤85% |
| Air pressure | ≤0.8MPa | ≤0.8MPa | ≤0.8MPa | ≤0.8MPa | ≤0.8MPa |
| Cooling water pressure | 0.2-0.4MPa | 0.2-0.4MPa | 0.2-0.4MPa | 0.2-0.4MPa | 0.2-0.4MPa |
| Production capacity | 10-30 pcs/min | 10-20pcs/min | 10-20pcs/min | 10-20pcs/min | 10-20pcs/min |
| Machine weight | 1.3Ton | 1.35Ton | 1.35Ton | 1.4Ton | 1.5Ton |
| Machine frame material | high-quality steel plate | high-quality steel plate & Alu. profile | high-quality steel plate & Alu. profile | high-quality steel plate & Alu. profile | high-quality steel plate & Alu. profile |
| Overall size | L1580,W1170, H1900mm | L1680,W1200,H1900mm | L1680,W1200, H1900mm | L1680,W1200, H1900mm | L1680,W1200, H1900mm |
| Chiller size | 720x490x855mm | 720x490x855mm | 720x490x855mm | 720x490x855mm | 720x490x855mm |
| Chiller weight | 38kg | 38kg | 38kg | 38kg | 38kg |
| Chiller power | 1500W | 1500W | 1500W | 1500W | 1500W |
| Cooling water flow | 15L/min | 15L/min | 15L/min | 15L/min | 15L/min |
B. Application
Suitable for stainless steel strip used in glass cover, basket, flour sieve, enamel pot, trash can, steamer and other daily hardware products. As a professional
Laser Welding Machine, it fits steel strip specifications of 10–200mm width and 0.1–1mm thickness, compatible with SS430/410/304/202/201, GI, Tinplate and other raw materials.
C. Advantages
Elegant in overall design and compact in layout, the
Automatic Welding Machine takes up little workshop space.
Adopting built-in fiber continuous laser design, it does not occupy extra external area.
It can handle 10–20 pieces per welding batch, bringing notable efficiency improvement.
It is highly applicable to seamless steel ring processing with superior welding finish and quality.
Reasonable and streamlined circuit layout makes this
Laser Equipment run more stably with lower power loss.
No professional skills or complicated steps are required; all operations are completed via HMI, only simple laser proportion parameter setting is needed.
D. Main configuration
Automatic forming servo tooling: self-made
Control system: Raynen
Fiber continuous laser: BWT/MAX
Cooling water chiller: Hanli
