A. Model and specifications
| Model | XC-K53-1000 | XC-K92-1000 | XC-K160-1000 |
| Laser power | 1000W | 1000W | 1000W |
| Steel strip width | 8-53mm | 45-92mm | 80-160mm |
| Welding capacity | 14-18 pcs/min | 12 pcs/min | 10pcs/min |
| Steel strip thickness | 0.13-0.7mm | 0.2-0.5mm | 0.2-0.4mm |
| Steel ring diameter | 65-700mm | 85-700mm | 120-700mm |
| Total machine power | 5kw | 5kw | 5kw |
| Input voltage | 220V | 220V | 220V |
| Nitrogen protection | Optional | Optional | Optional |
| Mark function | Optional | Optional | Optional |
| Cooling mode | Water | Water | Water |
| Machine weight | 1350kg | 1350kg | 1350kg |
| Overall size | 148x128x168 cm | 148x128x168 cm | 148x128x168 cm |
B. Application
Ideal for stainless steel strip processing of glass covers, baskets, flour sieves, enamel pots, trash cans, steamers and more. This Laser Welding Machine accommodates steel strip widths of 10–200mm and thicknesses of 0.1–1mm, supporting materials such as SS430/410/304/202/201, GI, and Tinplate.
C. Advantages
Elegant overall design with a compact structure that saves floor space.
Equipped with built-in fiber continuous laser, needing no extra external placement area.
Welding capacity reaches 10–20 pcs at a time, delivering greatly improved working efficiency.
Perfectly adapted for seamless steel ring processing, presenting outstanding welding finish and quality.
This Automatic Welding Machine adopts streamlined circuit layout, running steadily while saving energy consumption.
Operation is hassle-free via HMI interface; users only need to set the laser proportion without complicated steps. Its refined internal structure also makes this Laser Equipment reliable for long-term continuous production.
D. Main configuration
Automatic forming servo tooling: self-made
Control system: Raynen
Fiber continuous laser: BWT/MAX
Cooling water chiller: Hanli
E. Welding samples photos:
