Min. Order:1 Piece/Pieces
Model NO.: HYDR
Application: Electronic Industry, Automotive Industry, Manufacturing Industry
Technical Class: Continuous Wave Laser
Control: Automatic
Type: Automatic Laser Welding Machine
Cooling Method: Water Cooling
Number Of Robot Axes: 6-Axis
Fiber Laser Power: 3000W
Laser Wavelength: 1080±5nm
Transport Package: Seaworthy Package
Specification: According to the Machine Model
Trademark: Xin chang
Origin: Ningbo China
HS Code: 8515809090
Production Capacity: 100 Sets/Month
Customization: Available
After-sales Service: Good After-Sales Service
Warranty: 12 Months
Supply Ability: 100 Sets/Month
1. Machining trajectories are imported by the vision system.
2. Enclosure of the processing area to meet safety and environmental standards.
3. Informatization of process control, significantly improve production efficiency.
4. Real-time monitoring to realize closed-loop control.
5. Providing optimal solutions for three-dimensional workpiece machining.
6. Automation of production processes to reduce the labor intensity of employees.
| Robot Brands and Models | HYDR-20iB/10iD | |
| Robot | Maximum working radius on the outside of the robot | 1853mm |
| Robot Repeat positioning accuracy | ±0.03mm | |
| Number of robot axes | 6-axis | |
| Robot arm load | 20kg | |
| Weight of equipment (estimated) | 210KG | |
| Laser | Fiber laser power | 3000W |
| Laser wavelength | 1080±5nm | |
| Maximum cutting speed | Reference welding parameter table | |
| Thickness of processed material | Reference welding parameter table | |
| Water cooler | Cooling method | Water cooling |
| Machine | Continuous working time | 24 hours |
| Operating power | 380V ± 10%; 50Hz/60Hz | |
| Coaxial blowout requirements | 0.4-10MPa |
We, Ningbo Xin Chang Machinery Co.,Ltd are a professional designer and manufacturer in Friction Welding Machine, Resistance Welding Machine and Heat exchanger equipment. Our factory is in this line more than 20 years, we have more than 10 senior mechanical and electrical specialists and total more than 200 staff, our machine is famous in China. We have CCC, ISO9001 and CE certificates.
Over the years, we have exported so many machines to 30 and more countries, such as France,Spain,Poland,Russia,Indonesia,Vietnam,Pakistan,India,Mexico,Egypt etc.
Our main products are Heat exchanger equipment, Friction welding machine, Spot Welding Machine, Projection Welding Machine, Butt Welding Machine, Seam Welding Machine, Multi Head Welding Machine For Wire Mesh, and other various special welding machine for metal connection in different industries.
We always adhere to the management idea of "Integrity, profession, innovation, and win-win", to make Xin Chang becomes trustworthy enterprise of customers. Good product quality, perfect after-sales service, and professional technical support make customers choose no regrets and worry-free use
