Min. Order:1
Product advantages:
| SR | Name | Parameters |
| 1 | MF controller | 450A |
| 2 | Model | DNM-130KVA |
| 3 | Rated volt | 380V± 15% 50HZ |
| 4 | Rated capacity | 130KVA |
| 5 | Duty cycle(%) | 20 |
| 6 | Max short circuit current | 25 KA |
| 7 | Compressed air | 0.6-0.8 MPa |
| 8 | Throat depth | 200mm |
| 9 | Output copper braid wires | Single pc or double pc |
| 10 | Cycle time | 4-5 s per single wires |
| 11 | Insulation class | F |
| 12 | Cylinder stroke(mm) | 80 |
| 13 | Range of current(KA) | 0-25 |
| 14 | Cooling water pressure(Mpa) | 0.15 |
| 15 | Cooling water flow | 12 L/MIN |
