The Automation Reinforced Wire Mesh Bending Machine is a high-efficiency, precision automated equipment tailored for the bending processing of reinforced wire mesh. Widely applied in construction engineering, prefabricated component production, highway/railway infrastructure, and municipal engineering, this machine integrates hydraulic drive, intelligent control, and stable structural design to meet the high-precision bending needs of reinforced wire mesh in various scenarios, significantly improving production efficiency and reducing manual operational errors.
With excellent adaptability to wire mesh specifications, the machine supports a bending wire diameter range of 5mm-14mm, covering most common reinforced wire sizes used in construction projects. It can handle mesh widths from 25mm to 3300mm, enabling flexible processing of both small-sized mesh pieces and large-scale reinforced mesh panels, eliminating the limitation of conventional equipment on mesh size. Whether it is for bending mesh used in wall reinforcement, floor slabs, or bridge components, the machine can achieve precise and consistent bending effects.
In terms of bending performance, the machine boasts a stable bending speed of 6-8 strokes per minute, balancing efficiency and precision to meet the needs of large-batch production. Adopting a high-power hydraulic drive system, it delivers strong bending force, ensuring smooth and uniform bending even for thick 14mm diameter wires, without causing wire deformation or damage. The maximum bending angle can reach 180 degrees, supporting diverse bending requirements such as right-angle, obtuse-angle, and full-fold bending, fully matching the design needs of different construction projects.
Equipped with a robust bending structure, the machine can bend up to 33 wires at a time when processing 14mm diameter wires, greatly improving single-stroke processing capacity and overall production efficiency. This multi-wire simultaneous bending capability reduces the number of processing cycles, saving time and labor costs for enterprises.
In terms of power and structural configuration, the machine adopts a standard 380V/3P/50HZ power supply, which is compatible with most industrial power grids. It also provides customized power supply solutions to adapt to different regional power specifications, enhancing its applicability in global markets. With an overall power of 7.5KW, it achieves efficient energy conversion, ensuring stable operation while controlling energy consumption.
The machine features a compact and rational structural design, with an overall dimension of 3.5m×1.3m×2.2m, occupying a small footprint and facilitating integration into existing production lines or construction sites with limited space. Weighing 3.7 tons, it ensures structural stability during high-load bending operations, avoiding equipment displacement and ensuring long-term stable performance.
Beyond core performance, the machine is equipped with an intelligent control system, enabling intuitive parameter setting and real-time operation monitoring. Operators can easily adjust bending angle, speed, and quantity through the control panel, and store multiple sets of process parameters for different mesh specifications, realizing quick switching between production tasks. It also has built-in safety protection functions, such as overload protection and emergency stop, ensuring the safety of operators and equipment during operation.
As a professional reinforced wire mesh bending equipment, this machine integrates versatility, efficiency, and precision, providing a reliable automated solution for construction and prefabrication enterprises. It effectively addresses the pain points of low efficiency, poor consistency, and high labor intensity of manual bending, helping enterprises improve product quality, accelerate project progress, and enhance market competitiveness.
