Model
Item | AC-03 |
| Cooling Capacity | kcal/h | 8127 |
| KW | 9.45 |
| Input power | KW | 3.26 |
| Power Supply | 3PH~380V/50HZ |
| Refrigerant | Model | R22/407C |
| Control type | Expansion valve |
| Compressor | Type | Hermetic scroll type |
| Power | kw | 2.7 |
| Condenser | Type | High effective copper pipes lovered into aluminllm fins+low noise rotor fan |
| Power | kw | 0.19 |
| Cooling air Flow | m3/h | 3000 |
| Evaporator | Type | Water tank with coil |
| Refrigerated Water Flow | m3/h | 1.63 |
| Water Tank Capacity(L) | 50 |
| Inlet and Outlet pipe caliber | 1″ |
| Water Pump | Power (KW) | 0.37 |
| Lift(M) | 20 |
| Safety Protection | Compressor superheating protection, Overcurrent protection, High and low pressure protection, Over temperature protection, Phase sequence/ Phase-lacking protection, Exhaust over heating protection |
| Weight of the Machine | KG | 135 |
| MEAS. | MM | 930*520*975 |
Note: 1. The cooling capacity is according to:
Refrigerated water inlet and outlet temperature 17ºC/12ºC; Cooling water inlet and outlet temperature 30ºC/35ºC
2. Working Range:
The temperature range of Refrigerated water is from 5ºC to 35ºC; The inlet and outlet temperature difference is from 3ºC to 8ºC.
The temperature range of cooling water is from 18ºC to 35ºC; The inlet and outlet temperature difference of cooled water is from 3.5ºC to 10ºC.
We reserve the right to change the above dimensions or parameters without further notice.
