# Classification
Categorized by power source: AC and inverter DC
Categorized by welding wheel direction: horizontal and longitudinal
Categorized by quality grade: top quality and simple type
All above are standard models of the professional Seam Welding Machine.
# Features
1. Adopts 3-phase variable frequency motor to realize stable welding speed, convenient adjustment and reliable operation.
2. The welding circuit loop adopts internal water cooling, and the welding wheels (electrodes) adopt external water cooling.
3. The conductive rotating parts adopt embedded silver bushings, and the conductive base is sealed oil-lubricated and water-cooled to keep flexible rotation and avoid locking.
4. This Automated Seam Welding System can be customized into horizontal (H) and longitudinal (L) types for different working conditions.
# Core Advantages
1. The unique embedded silver bushing structure of conductive rotating parts, with sealed oil lubrication and water cooling, ensures stable and long-term rotation.
2. The rotating shaft in the conductive base is treated with nanometer ceramic spraying, which has stronger wear resistance than ordinary nylon and prolongs service life.
3. Square cylinder guide bar is adopted instead of round type, which effectively prevents welding wheel deflection and ensures more stable welding quality.
# Machine Composition
1. Machine body: vertical reinforced structure, welded with high-quality thick steel plate.
2. Transformer: made of 15000 gauss high-permeability silicon steel sheets, with internal water cooling and full copper alloy core, low impedance, high power utilization, 50% duty cycle for long-time welding, high output, long service life, low noise and compact structure.
3. Solenoid: Taiwan-made, high speed and stable performance.
4. Cylinder: high-precision anti-friction hard duralumin, rust-proof, low friction, low noise and fast pressure, reducing welding spatter.
5. Welding wheels: made of CuCrZr material with high wear resistance, water-cooled for longer service life.
6. Switches
7. Air source processor
8. Conductive base with silver bushing structure
9. Controller: Sunke, a top Chinese brand
10. Motor: Mitsubishi from Japan
11. Cooling water system
12. Compressed air system
13. Monitor & alarm system
# Applications
This Continuous Seam Welding Equipment is widely used in metal processing, electrical appliances, fuel tanks, water tanks and other industries. It is especially suitable for seam welding of basins, barrels, tanks and other sealed thin-walled containers made of low-carbon steel or stainless steel. | Model | FN-80-H(L) | FN-100-H(L) | FN-160-H(L) |
| Rated capacity | KVA | 80 | 100 | 160 |
| Primary voltage | V/PHASE | 380/1 | 380/1 | 380/1 |
| Frequency | HZ | 50 | 50 | 50 |
| Max. short circuit current | KA | 26 | 30 | 40 |
| Electrode stoke | mm | 100 | 100 | 100 |
| Welding speed | m/min | 0.7-3.9 | 0.7-3.9 | 0.7-3.9 |
| Electrode pressure | N | 6000 | 6000 | 7800 |
| Welding capacity(low carbon steel) | mm | 1.2+1.2 | 1.5+1.5 | 2.0+2.0 |
| Voltage of motor | V/PHASE | 380/3 | 380/3 | 380/3 |
| Power of motor | W | 550 | 750 | 750 |
| Cooling water flux | L/min | 8 | 8 | 10 |
| weight | Kg | 380 | 510 | 630 |
