# Classification
Power source: AC and inverter DC
Welding wheel direction: horizontal and longitudinal
Quality grade: top quality and simple type
Such diversified configurations make this Seam Welding Machine adaptable to various production scenarios.
# Features
1. It adopts a 3-phase variable frequency motor, which features stable welding speed, convenient adjustment and reliable operation.
2. The welding circuit loop is cooled by internal water cooling, and the welding wheels (electrodes) adopt external water cooling.
3. The conductive rotating parts of the welder adopt embedded silver bushings. The conductive base is lubricated by sealed oil and cooled by water, so that the silver bushings rotate flexibly without locking.
4. Two types of welding modes are available for this Automated Seam Welding System, namely horizontal type (H) and longitudinal type (L).
# Main Superiority Over Other Products
1. The conductive rotating parts adopt embedded silver bushing structure, and the conductive base is equipped with sealed oil lubrication and water cooling, which ensures flexible rotation and avoids locking.
2. The rotation axis inside the conductive base is treated with nanometer ceramic spraying, which is more wear-resistant than ordinary nylon materials, thus prolonging the service life of the machine.
3. The cylinder guidance bar adopts a square shape instead of a round one, which makes the welding wheel less prone to skewing and ensures better welding quality.
# Machine Composition
1. Machine body: designed with vertical reinforcing structure, welded by high-quality thick steel plates.
2. Transformer: stacked by silicon sheets with 15000 gauss permeability, equipped with internal cooling water and full copper alloy core, which reduces impedance, improves power utilization, supports 50% duty cycle to meet long-time welding needs with large output power, and features longer service life, lower noise and more compact structure.
3. Solenoid: imported from Taiwan, with high speed and reliable quality.
4. Cylinder: made of high-precision anti-friction hard duralumin, rust-proof, low friction, low noise and fast pressure-adding, thus reducing welding spatter.
5. Welding wheels: made of CuCrZr material with excellent wear resistance, and cooled by water for longer service life.
6. Switches
7. Air source processor
8. Conductive base with silver bushing structure
9. Controller: Sunke, a top brand in China
10. Motor: Mitsubishi from Japan
11. Cooling water system
12. Compressed air system
13. Monitor & alarm system
# Applications
This Continuous Seam Welding Equipment enjoys wide application in metal processing, electrical appliances, fuel tanks, water tanks and other fields. It is especially suitable for seam welding of basins, barrels, tanks and other sealed thin-walled containers made of low carbon steel or stainless steel. | Model | FN-80-H(L) | FN-100-H(L) | FN-160-H(L) |
| Rated capacity | KVA | 80 | 100 | 160 |
| Primary voltage | V/PHASE | 380/1 | 380/1 | 380/1 |
| Frequency | HZ | 50 | 50 | 50 |
| Max. short circuit current | KA | 26 | 30 | 40 |
| Electrode stoke | mm | 100 | 100 | 100 |
| Welding speed | m/min | 0.7-3.9 | 0.7-3.9 | 0.7-3.9 |
| Electrode pressure | N | 6000 | 6000 | 7800 |
| Welding capacity(low carbon steel) | mm | 1.2+1.2 | 1.5+1.5 | 2.0+2.0 |
| Voltage of motor | V/PHASE | 380/3 | 380/3 | 380/3 |
| Power of motor | W | 550 | 750 | 750 |
| Cooling water flux | L/min | 8 | 8 | 10 |
| weight | Kg | 380 | 510 | 630 |
