1, Adopt boosting charge and discharge capacotor.
2, Charging voltage with feedback control.
3, Machine body of thick steel sheet.
4, Welding current is DC.
5, With the functions that max protection of charging voltage and alarm of charging circuit loop break.
6, LED display.
7, Water cooling transformer: Use silicon sheets of 15000 gauss permeability to pile up.
8, Fast solenoid valve.
9, Cylinder adopt high accurate, anti-friction hard material, which is duralumin.
10, Quality is stable, failure rate is low.
11,Function:Suitable for steel,brass,copper alloy,aluminium etc.Special for electric appliance,watch chain,jewelry,tableware and other metal products.
ITEM
MODEL | Input capacity | Input voltage | Capacitance | Energy | Duty cycle | Max pressure | Operational stroke | Electrode stroke | Cooling water flux | Welding capacity (aluminium) |
| KVA | V | UF | J | % | N | MM | MM | L/Min | MM |
| DTR-3000 | 5 | 380 | 30000 | 3000 | 20 | 1900 | 30 | 70 | 2 | 1.2+1.2 |
| DTR-4500 | 5 | 380 | 45000 | 4500 | 20 | 1900 | 30 | 70 | 2 | 1.5+1.5 |
| DTR-6000 | 8 | 380 | 60000 | 6000 | 20 | 4800 | 30 | 70 | 3 | 2.0+2.0 |
| DTR-8000 | 8 | 380 | 80000 | 8000 | 20 | 7800 | 30 | 70 | 3 | 2.2+2.2 |
| DTR-10000 | 10 | 380 | 100000 | 10000 | 20 | 7800 | 30 | 70 | 3 | 2.4+2.4 |
| DTR-15000 | 15 | 380 | 150000 | 15000 | 20 | 7800 | 30 | 70 | 3 | 2.6+2.6 |
| DTR-20000 | 20 | 380 | 200000 | 20000 | 20 | 12000 | 30 | 70 | 3 | 3.0+3.0 |
| DTR-30000 | 30 | 380 | 300000 | 30000 | 20 | 12000 | 30 | 70 | 3 | 3.0+3.0 |
